1’X4′ 2’X2′ & 2’X4′ LED Troffer Lights | 5Watt & 5CCT Adjustable | 0-10V Dimming

1’X4′ 2’X2′ & 2’X4′ LED Troffer Lights | 5Watt & 5CCT Adjustable | 0-10V Dimming | TRF Series

Key Features

Watts:
1’X4′: 15/20/25/30/40W 5Watts Adjustable
2’X2′: 15/20/25/30/40W 5Watts Adjustable
2’X4′: 25/30/35/40/50W 5Watts Adjustable
Lumens Per Watt: 125
Voltage: 120-277V, 120-347V Optional
Color Temperature: 3.5/4/5/5.7/6.5K 5CCT Adjustable
CRI: 80+
Dimming: 0-10V
Beam Angles (Alt): 120°
Optics: Polycarbonate Lens
Lifespan: 50,000 hours
Mounting: Recessed
Fixture Color: White
Frequency: 50/60Hz
Power Factor: > 0.92
THD: < 15%

Durable Construction

Housing: Iron
IP Rating: /
IK Rating: /
Surge Protection: /
Operating Temperature: -30°F to +130°F
Certifications: ETL | DLC | FCC | CE | RoHS
Warranty: 5 years

Measurements

Dimensions: 1’X4′, 2’X2′, 2’X4′,
Weight:

Features/Accessories

PIR Sensor Optional
Microwave Sensor Optional
Audio-Jack Classic Socket Optional
Remote Controller Optional
Emergency Battery Backup Optional

Quote for bulk purchases of your business

Customizable Lighting to Suit Any Environment

This advanced Troffer Light comes with adjustable wattages and a customizable CCT range of 3500K, 4000K, 5000K, 5700K, and 6500K, eliminating the need to keep multiple color temperature fixtures in stock. It is the perfect lighting solution for office spaces, walkways, schools, shopping centers, and even industries like hospitality or healthcare.

Durable Construction for Long-Term Use

Engineered with a one-piece ribbed unitized housing and interlocking corners, this troffer prevents damage and increases durability. All edges are turned in and hemmed, ensuring safe handling and installation while maintaining a sleek aesthetic.

Unparalleled Performance and Versatility

Equipped with high-quality 120-277VAC and 120-347VAC drivers, this troffer delivers dependable performance. Featuring a glare-reducing optical system, its precision design ensures consistent and even light distribution. The fixture is 0-10V dimmable for ultimate control over brightness and energy efficiency.

Certifications and Warranty

This product is ETL cETL and DLC Premium listed, ensuring compliance with the highest industry standards. With a rated lifespan of 50,000 hours and a 5-year limited warranty, it’s a reliable and cost-effective choice for any setting. For specific warranty details, refer to your documentation.
